Head cutting machine

Product Description

The Head Cutting Machine—also called a mobile saddle hole CNC cutting system—is engineered for precision machining of tank heads used in pressure vessels and industrial containers. It delivers stable cutting performance for oval heads, butterfly heads, spherical crown heads, and other customized dish-end geometries.

Designed for manufacturers demanding long-term reliability and high efficiency, this machine offers superior control, safety, and flexibility across diverse production environments.

Product Overview

The head cutting machine is specifically developed for cutting end faces, weld bevels, grooves, and saddle holes on metal heads. Its integrated rotary table, gas cutting mechanism, and advanced electrical control cabinet ensure consistent accuracy with minimal operator effort.

Key Advantages

Simple operation and easy to learn
High cutting efficiency with stable rotation
Extremely low energy consumption
Safe and reliable with emergency stop features
Ideal for pressure vessel manufacturers of all sizes

Work Features

1. Stepless Speed Regulation

The variable-speed control system allows smooth adjustment for different cutting requirements,ensuring better process stability and easier maintenance.

2. Fast Workpiece Adjustment

When positioning the head on the working table, the operator simply releases the selector handle and rotates the table easily, improving setup speed and productivity.

3. Dual Control: Cabinet + Remote Control

The machine supports operation both through the main electrical cabinet and the handheld remote box. The rotary table can rotate clockwise or counterclockwise based on cutting needs.

System Structure

Rotary Table System

The system includes a table platform, mechanical base, turning mechanism, and self-locking transmission structure. The transmission route is: Motor → Two-stage reducer → Rotary table.

Electrical Control System

The electrical cabinet contains a frequency converter, contactors, fuses, control transformer, and protective modules to ensure safe and stable operation.

If rotation direction is incorrect, the machine will automatically limit the angle to prevent equipment damage.

Lubrication System

The worm gear reducer uses lubricating oil, while adjustment mechanisms and bearings use grease. Lubrication must be replaced regularly for optimal performance.

Technical Specifications

Model	Platform Diameter (mm)	Cutting Diameter (mm)	Motor Power (kW)	Rated Loading (T)
FQ-12	Φ600	Φ200–Φ1200	0.55	1.5
FQ-15	Φ1200	Φ300–Φ1500	0.75	3
FQ-35	Φ1400	Φ300–Φ3500	1.1	4
FQ-35 (Large)	Φ1600	Φ300–Φ5500	2.2	5

Applications

Finished heads processed by the machine are widely used in:

Air tanks
Water tanks
LPG tanks
Oil and fuel tanks
Chemical reactors
Boilers and energy storage equipment
Pressure vessels
Fire-fighting tanks
Food and beverage storage tanks
Stainless steel industrial containers

This makes the machine essential for industries such as:

Petrochemical
Gas supply systems
Energy and power
Water treatment
LNG/LPG manufacturing
Food processing
Pharmaceutical and biotech engineering

Company Profile

Dalian Jiuying Machinery Equipment Co., Ltd. was established in 2012 and specializes in manufacturing dish end forming machines, head spinning machines, flanging machines, cutting machines, and automated solutions for pressure vessel production.

Our products are exported to the United States, Italy, Russia, Vietnam, Mongolia, Georgia, Turkey, India, UAE, Algeria, Philippines, Indonesia, Malaysia, Bangladesh, South Africa, Germany, Slovakia, Sri Lanka, and more.

We follow a customer-first philosophy, continuously innovate, and offer high-tech, reliable industrial solutions.
